Item Designation Material 2" OD 2.5" OD 3" OD 4" OD
Butterfly valve
T-smart 711 (SS) cpl.
304 / EPDM 224-905.35 224-905.36 224-905.37 224-905.38
316L / EPDM 224-905.16 224-905.17 224-905.18 224-905.19
304 / FKM 224-915.35 224-915.36 224-915.37 224-915.38
316L / FKM 224-915.16 224-915.17 224-915.18 224-915.19
304 / HNBR 224-925.35 224-925.36 224-925.37 224-925.38
316L / HNBR 224-925.16 224-925.17 224-925.18 224-925.19
304 / VMQ 224-935.35 224-935.36 224-935.37 224-935.38
316L / VMQ 224-935.16 224-935.17 224-935.18 224-935.19
Sealing set SS cpl. EPDM 224-001340 224-001344 224-001348 224-001352
FKM 224-001341 224-001345 224-001349 224-001353
HNBR 224-001342 224-001346 224-001350 224-001354
VMQ 224-001343 224-001347 224-001351 224-001355
1 Flap 304 224-001009 224-001010 224-001011 224-001012
316L 224-000812 224-000813 224-000814 224-000815
2 Seal EPDM 224-170.63 224-170.64 224-170.65 224-170.66
FKM 224-170.77 224-170.78 224-170.79 224-170.80
HNBR 224-170.91 224-170.92 224-170.93 224-170.94
VMQ 224-173.07 224-173.08 224-173.09 224-173.10
3 Round plug PE 922-338 922-338 922-338 922-338
4 Cheese head screw A2-70 4x 902-100 4x 902-100 6x 902-100 6x 902-100
M8 x 30 M8 x 30 M8 x 30 M8 x 30
5 Hexagon nut A2 4x 910-018 4x 910-018 6x 910-018 6x 910-018
M8 M8 M8 M8
21 Plain bearing IGLIDUR F 704-045 704-045 704-045 704-045
A Flange see Overview of flanges
Grease RIVOLTA F.L.G. MD-2 100g tube not included in the sealing set.
Grease BARRIERTA L 55/3 (only for seals VMQ)
413-136
413-137
Items 2 and 21 are included in the sealing set 429-043
Parts list - Butterfly valve body T-smart 7
430BAL009990EN_2
30.01.2018 65
