GEA T-smart 7 User Manual

Item Designation Material DN 15 DN 20 DN 25 DN 40 DN 50
1 Welded flange 304 224-000899 224-000900 224-000901 224-000902 224-000903
316L 224-000705 224-000706 224-000707 224-000708 224-000709
2 Threaded flange DIN 304 -- -- 224-000945 224-000946 224-000947
316L -- -- 224-000721 224-000722 224-000723
3 Clamp flange 304 -- -- 224-000933 224-000934 224-000935
316L -- -- 224-000735 224-000736 224-000737
4 Cone flange DIN 304 -- -- on request on request on request
316L -- -- on request on request on request
Item Designation Material DN 65 DN 80 DN 100 DN 125 DN 150
1 Welded flange 304 224-000904 224-000905 224-000906 224-000907 224-000908
316L 224-000710 224-000711 224-000712 224-000713 224-000714
2 Threaded flange DIN 304 224-000948 224-000949 224-000950 224-000951 224-000952
316L 224-000724 224-000725 224-000726 224-000727 224-000728
3 Clamp flange 304 224-000936 224-000937 224-000938 -- --
316L 224-000738 224-000739 224-000740 -- --
4 Cone flange DIN 304 on request on request on request on request on request
316L on request on request on request on request on request
Parts list - Butterfly valve body T-smart 7
430BAL009990EN_2
66 30.01.2018
