GEA T-smart 7 User Manual

Item Designation Material 0.5" OD 0.75" OD 1" OD 1.5" OD
1 Welded flange 304 224-000915 224-000899 224-000909 224-000910
316L 224-000816 224-000705 224-000715 224-000716
2 Threaded flange DIN 304 -- -- 224-000978 224-000979
316L -- -- 224-000729 224-000730
3 Clamp flange 304 -- -- 224-000939 224-000940
316L -- -- 224-000741 224-000742
4 Cone flange DIN 304 -- -- on request on request
316L -- -- on request on request
2a Threaded flange RJT
304 -- -- 224-000965 224-000966
316L -- -- 224-000784 224-000785
2b Threaded flange IDF
304 -- -- 224-000953 224-000954
316L -- -- 224-000790 224-000791
2c/1 Threaded flange SMS
304 -- -- 224-000971 224-000972
316L -- -- 224-000777 224-000778
2c/2 Threaded flange DS
304 -- -- 224-000959 224-000960
316L -- -- 224-000796 224-000797
4a Cone flange SMS
304 -- -- on request on request
316L -- -- on request on request
Item Designation Material 2" OD 2.5" OD 3" OD 4" OD
1 Welded flange 304 224-000911 224-000912 224-000913 224-000914
316L 224-000717 224-000718 224-000719 224-000720
2 Threaded flange DIN 304 224-000980 224-000981 224-000982 224-000983
316L 224-000731 224-000732 224-000733 224-000734
3 Clamp flange 304 224-000941 224-000942 224-000943 224-000944
316L 224-000743 224-000744 224-000745 224-000746
4 Cone flange DIN 304 on request on request on request on request
316L on request on request on request on request
2a Threaded flange RJT
304 224-000967 224-000968 224-000969 224-000970
316L 224-000786 224-000787 224-000788 224-000789
2b Threaded flange IDF
304 224-000955 224-000956 224-000957 224-000958
316L 224-000792 224-000793 224-000794 224-000795
2c/1 Threaded flange SMS 304 224-000973 224-000974 224-000975 224-000976 *
224-000977 **
316L 224-000779 224-000780 224-000781 224-000782 *
224-000783 **
2c/2 Threaded flange DS
304 224-000961 224-000962 224-000963 224-000964
316L 224-000798 224-000799 224-000800 224-000801
4a Cone flange SMS
304 on request on request on request on request
316L on request on request on request on request
* until April 2017 (Rd 125)
** from April 2017 (Rd 132)
Parts list - Butterfly valve body T-smart 7
430BAL009990EN_2
30.01.2018 67
