Item Designation Material DN 25 DN 40 DN 50 DN 65 DN 80 DN 100 DN 125 DN 150
G Sealing ring G for
threaded flange
DIN
EPDM 928-338 928-340 928-341 928-342 928-343 928-344 928-349 928-368
FKM 928-324 928-325 928-326 928-327 928-328 928-329 928-350 928-376
HNBR 928-758 928-759 928-760 928-761 928-762 928-763 928-764 928-765
VMQ 928-796 928-797 928-798 928-799 928-800 928-801 928-802 928-803
Item Designation Material 1" OD 1.5" OD 2" OD 2.5" OD 3" OD 4" OD
G Sealing ring G for
threaded flange
DIN
EPDM 928-338 928-340 928-341 928-342 928-793 928-344
FKM 928-324 928-325 928-326 928-327 928-794 928-329
HNBR 928-758 928-759 928-760 928-761 -- 928-763
VMQ 928-796 928-797 928-798 928-799 -- 928-801
Designation Material DN 25 DN 40 DN 50 DN 65
Butterfly valve T-smart 721
(GS) cpl.
304 / EPDM 224-907.22 224-907.24 224-907.25 224-907.26
316L / EPDM 224-907.03 224-907.05 224-907.06 224-907.07
304 / FKM 224-917.22 224-917.24 224-917.25 224-917.26
316L / FKM 224-917.03 224-917.05 224-917.06 224-917.07
304 / HNBR 224-927.22 224-927.24 224-927.25 224-927.26
316L / HNBR 224-927.03 224-927.05 224-927.06 224-927.07
304 / VMQ 224-937.22 224-937.24 224-937.25 224-937.26
316L / VMQ 224-937.03 224-937.05 224-937.06 224-937.07
Butterfly valve T-smart 722
(GG) cpl.
304 / EPDM 224-909.22 224-909.24 224-909.25 224-909.26
316L / EPDM 224-909.03 224-909.05 224-909.06 224-909.07
304 / FKM 224-919.22 224-919.24 224-919.25 224-919.26
316L / FKM 224-919.03 224-919.05 224-919.06 224-919.07
304 / HNBR 224-929.22 224-929.24 224-929.25 224-929.26
316L / HNBR 224-929.03 224-929.05 224-929.06 224-929.07
304 / VMQ 224-939.22 224-939.24 224-939.25 224-939.26
316L / VMQ 224-939.03 224-939.05 224-939.06 224-939.07
Parts list - Butterfly valve body T-smart 7
430BAL009990EN_2
68 30.01.2018
