GEA T-smart 7 User Manual

Item Designation Material DN 15 DN 20 DN 25 DN 40
Butterfly valve
T-smart 788 (VV) complete
304 / EPDM 224-906.20 224-906.21 224-906.22 224-906.24
316L / EPDM 224-906.01 224-906.02 224-906.03 224-906.05
304 / FKM 224-916.20 224-916.21 224-916.22 224-916.24
316L / FKM 224-916.01 224-916.02 224-916.03 224-916.05
304 / HNBR 224-926.20 224-926.21 224-926.22 224-926.24
316L / HNBR 224-926.01 224-926.02 224-926.03 224-926.05
304 / VMQ 224-936.20 224-936.21 224-936.22 224-936.24
316L / VMQ 224-936.01 224-936.02 224-936.03 224-936.05
Sealing set VV complete EPDM 224-001388 224-001388 224-001356 224-001360
FKM 224-001389 224-001389 224-001357 224-001361
HNBR 224-001390 224-001390 224-001358 224-001362
VMQ 224-001391 224-001391 224-001359 224-001363
1 Butterfly valve disc 304 224-001007 224-001007 224-000999 224-001000
316L 224-000810 224-000810 224-000802 224-000803
2 Butterfly valve seal EPDM 224-170.61 224-170.61 224-170.67 224-170.68
FKM 224-170.75 224-170.75 224-170.81 224-170.82
HNBR 224-170.89 224-170.89 224-170.95 224-170.96
VMQ 224-173.05 224-173.05 224-173.11 224-173.12
3 Round plug PE 922-338 922-338 922-338 922-338
4 Cheese head screw A2-70 4x 902-135 4x 902-135 4x 902-135 4x 902-135
M6 x 75 M6 x 75 M6 x 75 M6 x 75
5 Hex nut A2 8x 910-013 8x 910-013 8x 910-013 8x 910-013
M6 M6 M6 M6
15 Cheese head screw A2-70 4x 902-099 4x 902-099 4x 902-099 4x 902-099
M6 x 30 M6 x 30 M6 x 30 M6 x 30
18 O-ring EPDM 930-376 930-376 930-393 930-545
FKM 930-593 930-593 930-564 930-566
HNBR 930-851 930-851 930-551 930-552
VMQ 930-066 930-066 930-072 930-074
19 Flange V, int. 304 224-000992 224-000992 224-000984 224-000985
316L 224-000755 224-000755 224-000747 224-000748
20 Flange V, ext. 304 224-000931 224-000932 224-000916 224-000917
316L 224-000818 224-000819 224-000762 224-000764
21 Plain bearing IGLIDUR-F 704-045 704-045 704-045 704-045
Grease RIVOLTA F.L.G. MD-2 100g tube not included in the sealing set.
Grease BARRIERTA L 55/3 (only for seals VMQ)
413-136
413-137
Items 2, 18 and 21 are included in the sealing set 429-044
Parts list - Butterfly valve 788
430BAL009990EN_2
78 30.01.2018
