Item Designation Material DN 50 DN 65 DN 80
Butterfly valve
T-smart 788 (VV) complete
304 / EPDM 224-906.25 224-906.26 224-906.27
316L / EPDM 224-906.06 224-906.07 224-906.08
304 / FKM 224-916.25 224-916.26 224-916.27
316L / FKM 224-916.06 224-916.07 224-916.08
304 / HNBR 224-926.25 224-926.26 224-926.27
316L / HNBR 224-926.06 224-926.07 224-926.08
304 / VMQ 224-936.25 224-936.26 224-936.27
316L / VMQ 224-936.06 224-936.07 224-936.08
Sealing set VV complete EPDM 224-001364 224-001368 224-001372
FKM 224-001365 224-001369 224-001373
HNBR 224-001366 224-001370 224-001374
VMQ 224-001367 224-001371 224-001375
1 Butterfly valve disc 304 224-001001 224-001002 224-001003
316L 224-000804 224-000805 224-000806
2 Butterfly valve seal EPDM 224-170.69 224-170.70 224-170.71
FKM 224-170.83 224-170.84 224-170.85
HNBR 224-170.97 224-170.98 224-170.99
VMQ 224-173.13 224-173.14 224-173.15
3 Round plug PE 922-338 922-338 922-338
4 Cheese head screw A2-70 4x 902-136 6x 902-136 6x 902-136
M8 x 75 M8 x 75 M8 x 75
5 Hex nut A2 8x 910-018 12x 910-018 12x 910-018
M8 M8 M8
15 Cheese head screw A2-70 4x 902-100 6x 902-100 6x 902-100
M8 x 30 M8 x 30 M8 x 30
18 O-ring EPDM 930-546 930-547 930-450
FKM 930-567 930-526 930-527
HNBR 930-553 930-554 930-555
VMQ 930-075 930-076 930-078
19 Flange V, int. 304 224-000986 224-000987 224-000988
316L 224-000749 224-000750 224-000751
20 Flange V, ext. 304 224-000918 224-000919 224-000920
316L 224-000765 224-000766 224-000767
21 Plain bearing IGLIDUR-F 704-045 704-045 704-045
Grease RIVOLTA F.L.G. MD-2 100g tube not included in the sealing set.
Grease BARRIERTA L 55/3 (only for seals VMQ)
413-136
413-137
Items 2, 18 and 21 are included in the sealing set 429-044
Parts list - Butterfly valve 788
430BAL009990EN_2
30.01.2018 79
