Item Designation Material DN 100 DN 125 DN 150
Butterfly valve
T-smart 788 (VV) complete
304 / EPDM 224-906.28 224-906.29 224-906.30
316L / EPDM 224-906.09 224-906.10 224-906.11
304 / FKM 224-916.28 224-916.29 224-916.30
316L / FKM 224-916.09 224-916.10 224-916.11
304 / HNBR 224-926.28 224-926.29 224-926.30
316L / HNBR 224-926.09 224-926.10 224-926.11
304 / VMQ 224-936.28 224-936.29 224-936.30
316L / VMQ 224-936.09 224-936.10 224-936.11
Sealing set VV complete EPDM 224-001376 224-001380 224-001384
FKM 224-001377 224-001381 224-001385
HNBR 224-001378 224-001382 224-001386
VMQ 224-001379 224-001383 224-001387
1 Butterfly valve disc 304 224-001004 224-001005 224-001006
316L 224-000807 224-000808 224-000809
2 Butterfly valve seal EPDM 224-170.72 224-170.73 224-170.74
FKM 224-170.86 224-170.87 224-170.88
HNBR 224-173.02 224-173.03 224-173.04
VMQ 224-173.16 224-173.17 224-173.18
3 Round plug PE 922-338 922-339 922-339
4 Cheese head screw A2-70 8x 902-136 8x 902-133 8x 902-132
M8 x 75 M10 x 100 M12 x 110
5 Hex nut A2 14x 910-018 14x 910-026 16x 10-029
M8 M10 M12
15 Cheese head screw A2-70 6x 902-100 6x 902-118 8x 902-134
M8 x 30 M10 x 35 M12 x 40
18 O-ring EPDM 930-549 930-550 930-574
FKM 930-568 930-569 930-575
HNBR 930-556 930-557 930-872
VMQ 930-079 930-084 930-085
19 Flange V, int. 304 224-000989 224-000990 224-000991
316L 224-000752 224-000753 224-000754
20 Flange V, ext. 304 224-000921 224-000922 224-000923
316L 224-000768 224-000769 224-000770
21 Plain bearing IGLIDUR-F 704-045 704-046 704-046
Grease RIVOLTA F.L.G. MD-2 100g tube not included in the sealing set.
Grease BARRIERTA L 55/3 (only for seals VMQ)
413-136
413-137
Items 2, 18 and 21 are included in the sealing set 429-044
Parts list - Butterfly valve 788
430BAL009990EN_2
80 30.01.2018
