Item Designation Material 0.5" OD 0.75" OD 1" OD 1.5" OD
Butterfly valve
T-smart 788 (VV) complete
304 / EPDM 224-906.31 224-906.20 224-906.33 224-906.34
316L / EPDM 224-906.12 224-906.01 224-906.14 224-906.15
304 / FKM 224-916.31 224-916.20 224-916.33 224-916.34
316L / FKM 224-916.12 224-916.01 224-916.14 224-916.15
304 / HNBR 224-926.31 224-926.20 224-926.33 224-926.34
316L / HNBR 224-926.12 224-926.01 224-926.14 224-926.15
304 / VMQ 224-936.31 224-936.20 224-936.33 224-936.34
316L / VMQ 224-936.12 224-936.01 224-936.14 224-936.15
Sealing set VV complete EPDM 224-001388 224-001388 224-001388 224-001392
FKM 224-001389 224-001389 224-001389 224-001393
HNBR 224-001390 224-001390 224-001390 224-001394
VMQ 224-001391 224-001391 224-001391 224-001395
1 Butterfly valve disc 304 224-001007 224-001007 224-001007 224-001008
316L 224-000810 224-000810 224-000810 224-000811
2 Butterfly valve seal EPDM 224-170.61 224-170.61 224-170.61 224-170.62
FKM 224-170.75 224-170.75 224-170.75 224-170.76
HNBR 224-170.89 224-170.89 224-170.89 224-170.90
VMQ 224-173.05 224-173.05 224-173.05 224-173.06
3 Round plug PE 922-338 922-338 922-338 922-338
4 Cheese head screw A2-70 4x 902-135 4x 902-135 4x 902-135 4x 902-135
M6 x 75 M6 x 75 M6 x 75 M6 x 75
5 Hex nut A2 8x 910-013 8x 910-013 8x 910-013 8x 910-013
M6 M6 M6 M6
15 Cheese head screw A2-70 4x 902-099 4x 902-099 4x 902-099 4x 902-099
M6 x 30 M6 x 30 M6 x 30 M6 x 30
18 O-ring EPDM 930-376 930-376 930-376 930-497
FKM 930-593 930-593 930-593 930-570
HNBR 930-851 930-851 930-851 930-852
VMQ 930-066 930-066 930-066 930-067
19 Flange V, int. 304 224-000992 224-000992 224-000992 224-000993
316L 224-000755 224-000755 224-000755 224-000756
20 Flange V, ext. 304 224-000930 224-000931 224-000924 224-000925
316L 224-000817 224-000818 224-000771 224-000772
21 Plain bearing IGLIDUR-F 704-045 704-045 704-045 704-045
Grease RIVOLTA F.L.G. MD-2 100g tube not included in the sealing set.
Grease BARRIERTA L 55/3 (only for seals VMQ)
413-136
413-137
Items 2, 18 and 21 are included in the sealing set 429-044
Parts list - Butterfly valve 788
430BAL009990EN_2
30.01.2018 81
