Item Designation Material 2" OD 2.5" OD 3" OD 4" OD
Butterfly valve
T-smart 788 (VV) complete
304 / EPDM 224-906.35 224-906.36 224-906.37 224-906.38
316L / EPDM 224-906.16 224-906.17 224-906.18 224-906.19
304 / FKM 224-916.35 224-916.36 224-916.37 224-916.38
316L / FKM 224-916.16 224-916.17 224-916.18 224-916.19
304 / HNBR 224-926.35 224-926.36 224-926.37 224-926.38
316L / HNBR 224-926.16 224-926.17 224-926.18 224-926.19
304 / VMQ 224-936.35 224-936.36 224-936.37 224-936.38
316L / VMQ 224-936.16 224-936.17 224-936.18 224-936.19
Sealing set VV complete EPDM 224-001396 224-001400 224-001404 224-001408
FKM 224-001397 224-001401 224-001405 224-001409
HNBR 224-001398 224-001402 224-001406 224-001410
VMQ 224-001399 224-001403 224-001407 224-001411
1 Butterfly valve disc 304 224-001009 224-001010 224-001011 224-001012
316L 224-000812 224-000813 224-000814 224-000815
2 Butterfly valve seal EPDM 224-170.63 224-170.64 224-170.65 224-170.66
FKM 224-170.77 224-170.78 224-170.79 224-170.80
HNBR 224-170.91 224-170.92 224-170.93 224-170.94
VMQ 224-173.07 224-173.08 224-173.09 224-173.10
3 Round plug PE 922-338 922-338 922-338 922-338
4 Cheese head screw A2-70 4x 902-136 6x 902-136 6x 902-136 8x 902-136
M8 x 75 M8 x 75 M8 x 75 M8 x 75
5 Hex nut A2 8x 910-018 10x 910-018 12x 910-018 14x 910-018
M8 M8 M8 M8
15 Cheese head screw A2-70 4x 902-100 4x 902-100 6x 902-100 6x 902-100
M8 x 30 M8 x 30 M8 x 30 M8 x 30
18 O-ring EPDM 930-559 930-560 930-319 930-561
FKM 930-571 930-572 930-666 930-573
HNBR 930-853 930-854 930-652 930-855
VMQ 930-068 930-069 930-070 930-071
19 Flange V, int. 304 224-000994 224-000995 224-000996 224-000997
316L 224-000758 224-000759 224-000760 224-000761
20 Flange V, ext. 304 224-000926 224-000927 224-000928 224-000929
316L 224-000773 224-000774 224-000775 224-000776
21 Plain bearing IGLIDUR-F 704-045 704-045 704-045 704-045
Grease RIVOLTA F.L.G. MD-2 100g tube not included in the sealing set.
Grease BARRIERTA L 55/3 (only for seals VMQ)
413-136
413-137
Items 2, 18 and 21 are included in the sealing set 429-044
Parts list - Butterfly valve 788
430BAL009990EN_2
82 30.01.2018
