117
145
U
3 / 4
Sensormanager sensor 3
Analog value
1
146
U
3 / 4
Sensormanager sensor 4
Analog value
1
147
U
3 / 4
Sensormanager sensor 5
Analog value
1
148
U
3 / 4
Sensormanager sensor 6
Analog value
1
149
U
3 / 4
Sensormanager sensor 7
Analog value
1
150
U
3 / 4
Sensormanager sensor 8
Analog value
1
Section OEM
NEWAVE UPS
99
U
1 6
Timesyncronization signal
Command 16 (write) : When
this signal is set, the CS121
sets the internal clock to
01:00 of the same day.
Command 3 or 4 (read) is not
allowed.
1
139
U
3 / 4
Manual Bypass Switch Closed
0 = open
1 = closed
1
140
U
3 / 4
OUTPUT_VOLT0
Outputvoltage Phase 1
1
141
U
3 / 4
OUTPUT_VOLT1
Outputvoltage Phase 2
1
142
U
3 / 4
OUTPUT_VOLT2
Outputvoltage Phase 3
1
143
U
3 / 4
OutputCurrent Phase A * 10
Output Current Phase 1 in
Ampere *10
1
144
U
3 / 4
OutputCurrent Phase B * 10
Output Current Phase 1 in
Ampere *10
1
145
U
3 / 4
OutputCurrent Phase C * 10
Output Current Phase 1 in
Ampere *10
1
146
U
3 / 4
xid3017 Bits 0-15
Statusbit of UPS 1 = true, 0 =
false
1
147
U
3 / 4
xid3017 Bits 16-31
Statusbit, for details please
contact NEWAVE
1
148
U
3 / 4
xid645 Bits 0-15
Alarmbit, for details please
contact NEWAVE
1
149
U
3 / 4
xid645 Bits 16-31
Alarmbit, for details please
contact NEWAVE
1
150
U
3 / 4
xid645 Bits 32-47
Alarmbit, for details please
contact NEWAVE
1
151
U
3 / 4
xid645 Bits 48-63
Alarmbit, for details please
contact NEWAVE
1
152
U
3 / 4
Sensormanager/SMTCOM sensor
1
Analog value
1
153
U
3 / 4
Sensormanager/SMTHCOM
sensor 2
Analog value
1
154
U
3 / 4
Sensormanager sensor 3
Analog value
1
155
U
3 / 4
Sensormanager sensor 4
Analog value
1
156
U
3 / 4
Sensormanager sensor 5
Analog value
1
157
U
3 / 4
Sensormanager sensor 6
Analog value
1
158
U
3 / 4
Sensormanager sensor 7
Analog value
1
159
U
3 / 4
Sensormanager sensor 8
Analog value
1
160
U
3 / 4
TrueOutputPower Phase A in KW
True Output Power Current
Phase 1 in Kilowatt
1
161
U
3 / 4
TrueOutputPower Phase A in KW
True Output Power Current
Phase 1 in Kilowatt
1
162
U
3 / 4
TrueOutputPower Phase A in KW
True Output Power Current
Phase 1 in Kilowatt
1
