Generex CS121L - E.6. UPSMAN Status Bytes - Standard Device Status Bits

138
UPS Status EverExceed
Hex-Value
Dec-Value
Description
UPS_SB_BYPASS_MODE
0x0001
1
Bypass mode
UPS_SB_OUTPUT_ACT
0x0004
4
Output active
UPS_SB_OUTPUT_HIGH
0x0100
256
Overload
UPS_SB_UPS_FAILED
0x2000
8192
General alarm
Section
Gamatronic DC System
100
U
3 / 4
TEMPDEG
Temperature in Degrees
1
101
U
3 / 4
INVOLT0
AC Input Voltage Phase 1
1
102
U
3 / 4
OUTPUT_VOLT0
DC Output Voltage
1
103
U
3 / 4
EX_OUT_CURR0
Total Output Current
1
104
U
3 / 4
EX_OUT_WATT0
Output Power in Watt
1
105
U
3 / 4
BATTVOLT
Battery Voltage
1
106
U
3 / 4
EX_BATT_CURRPOS
Battery Current
1
107
U
3 / 4
EX_NOM_VOLT
Nominal Voltage
1
108
U
3 / 4
EX_NOM_CURR
Nominal Current
1
109
U
3 / 4
STATUS
GENEREX UPS Status (see below)
1
110
U
3 / 4
(EX_EXTSTATUS & 0xffff0000)>>16
Bytes 98-99 (Device Status)
1
111
U
3 / 4
EX_EXTSTATUS & 0xffff
Bytes 100-101 (Device Status)
1
112
U
3 / 4
(STATUS&0x02)>>2
Output active, 1 = on, 0 = off
1
113
U
3 / 4
(STATUS&0x20)>>5
Overtemperature, 1 = on, 0 = off
1
114
U
3 / 4
(STATUS&0x40)>>6
Test active, 1 = on, 0 = off
1
115
U
3 / 4
(STATUS&0x100)>>8
Overload, 1 = on, 0 = off
1
116
U
3 / 4
(STATUS&0x2000)>>13
General alarm, 1 = on, 0 = off
1
UPS Status Gamatronic DC System
Hex-Value
Dec-Value
Description
UPS_SB_OUTPUT_ACT
0x0004
4
Output active
UPS_SB_OVER_TEMP
0x0020
32
Overtemperature
UPS_SB_TEST_ACT
0x0040
64
Test active
UPS_SB_OUTPUT_HIGH
0x0100
256
Overload
UPS_SB_UPS_FAILED
0x2000
8192
General alarm
Other OEM’s
->See OEM MODBUS
documentation
E.6. UPSMAN Status Bytes - Standard Device Status Bits
