Generex CS121L - Page 124

122
153
U
3 / 4
TEMP2
SensorManager/SM_T_H_CO
M Analog Value
1
154
U
3 / 4
TEMP3
SensorManager Analog Value
1
155
U
3 / 4
TEMP4
SensorManager Analog Value
1
156
U
3 / 4
TEMP5
SensorManager Analog Value
1
157
U
3 / 4
TEMP6
SensorManager Analog Value
1
158
U
3 / 4
TEMP7
SensorManager Analog Value
1
159
U
3 / 4
TEMP8
SensorManager Analog Value
1
160
U
3 / 4
LOADKVA0
Load Phase 1 in KW
1
161
U
3 / 4
LOADKVA1
Load Phase 2 in KW
1
162
U
3 / 4
LOADKVA2
Load Phase 3 in KW
1
Section OEM
Netminder for all LT and MD types
Address
Type
Function
Name
Description
Length
100
U
3/4
INVOLT
Input Voltage
1
101
U
3/4
OUTPUTVOLT
Output Voltage
1
102
U
3/4
BATTVOLT
Battery Voltage
1
103
U
3/4
OUTPUTCURR
Output Current
1
104
U
3/4
LOADPERC
Load (%)
1
105
U
3/4
OUTPUTPOW
Output Power in W
1
106
U
3/4
KVA
KVA
1
107
U
3/4
FREQUENCY
Frequency
1
108
U
3/4
CS121UPSSTAT
CS121 UPS Status
1
109
U
3/4
Alarm: Battery Bad
1 = active; 0 = not active
1
110
U
3/4
Alarm: On Battery
1 = active; 0 = not active
1
111
U
3/4
Alarm: Battery Low
1 = active; 0 = not active
1
112
U
3/4
Alarm: Battery Depleted
1 = active; 0 = not active
1
113
U
3/4
Alarm: Overtemperature
1 = active; 0 = not active
1
114
U
3/4
Alarm: Input Bad
1 = active; 0 = not active
1
115
U
3/4
Alarm: Output Bad
1 = active; 0 = not active
1
116
U
3/4
Alarm: Output Overload
1 = active; 0 = not active
1
117
U
3/4
Alarm: On Bypass
1 = active; 0 = not active
1
118
U
3/4
Alarm: Bypass Bad
1 = active; 0 = not active
1
119
U
3/4
Alarm: Output Off As
Requested
1 = active; 0 = not active
1
120
U
3/4
Alarm: UPS Off As
Requested
1 = active; 0 = not active
1
