127
148
U
3/4
AUX Port 2
1 = active (high) ; 0 = not
active (low)
1
149
U
3/4
AUX Port 3
1 = active (high) ; 0 = not
active (low)
1
150
U
3/4
AUX Port 4
1 = active (high) ; 0 = not
active (low)
1
151
U
3/4
SensorManager/SMTH_COM,
Sensor 1
Analog Value
1
152
U
3/4
SensorManager/SMTH_COM,
Sensor 2
Analog Value
1
153
U
3/4
SensorManager/Sensor 3
Analog Value
1
154
U
3/4
SensorManager/Sensor 4
Analog Value
1
155
U
3/4
SensorManager/Sensor 5
Analog Value
1
156
U
3/4
SensorManager/Sensor 6
Analog Value
1
157
U
3/4
SensorManager/Sensor 7
Analog Value
1
158
U
3/4
SensorManager/Sensor 8
Analog Value
1
Secti
on
OEM
POWERTRONIX
MIZAR
Adres
se
Name
ALCOR
QUASAR
SUPERNOVAE
100
Outpower Phase 1 %
x
x
x
101
Outpower Phase 2 %
x
x
x
102
Outpower Phase 3 %
x
x
x
103
Battery Capacity %
x
x
x
104
Input Voltage Phase 1 V
x
x
x
105
Input Voltage Phase 2 V
x
x
x
106
Input Voltage Phase 3 V
x
x
x
107
Temperature °C
not supported
x
x
108
Autonomy Time minutes
x
x
x
109
UPS Status (ASCII Hex)
x
x
x
110
Battery Voltage V
x
x
x
111
Input Frequency Phase 1 Hz
not supported
x
not supported
