146
Booster Off
Voltage booster of battery is off
Battery Discharging
Battery discharging
Battery Charging
Battery charging
Load Is Supplied
Load is supplied, normal condition
Fuses Failure
Fuses failure
Fuses Ok
Fuses Ok
Battery Grounding Error
Battery grounding error
Generator On
Generator on
Generator Off
Generator off
Output Normal
Output normal, normal condition
Redundancy Ok
Redundancy is at hand
AUX Port 1 High
AUX port 1 opened
AUX Port 2 High
AUX port 2 opened
AUX Port 3 High
AUX port 3 opened
AUX Port 4 High
AUX port 4 opened
AUX Port 1 Low
AUX port 1 closed
AUX Port 2 Low
AUX port 2 closed
AUX Port 3 Low
AUX port 3 closed
AUX Port 4 Low
AUX port 4 closed
Schematic drawing of an UPS, e. g. NEWAVE
Yellow = Fuse
Blue = Automatic breaker
Green = Manual Breaker
