4.4 Replace bulb of the front turning
light
4.4.1 Disassembly
Remove front shield of handle pipe.
Disconnect connecting wire of front turn signal lamp.
Unscrew the setscrew on the turning light.
Remove the bulb socket from the light.
4.4.2 Installation
Install the bulb back to the original position in the reverse
order of disassembly.
4.5 Disassembly/replace the bulb of
the taillight and rear-right turning
light
4.5.1 Disassembly
Remove seat cushion.
Remove set screws of left and right rear fenders so that tail
lamp shade can be taken off.
Disconnect wire connectors of tail lamp and left and right
turn signal lamps.
Remove left and right rear fenders (1), tail lamp shade and
rear license bracket. Remove tail lamp (4).
Remove tail lamp (4) and rear left and right turn signal
lamps.
4.5.2 Installation
Install the taillight back to the original position in the reverse
order of disassembly.
4.5.3 Replace the bulb of the taillight
4.5.3.1 Disassembly
Remove set screws of tail lamp shade.
Remove tail lamp shade together with tail lamp bulb.
Remove bulbs (left and right turn signal lamp bulbs and tail lamp bulb) from bulb holders.
