Generic Race 50 - Inspection and Service of Chassis

104
Inspection and Service of Chassis
Table of Torques for Fasteners on Chassis
Fastening location and name of fastener Tightening torque (N·m)
Fixing bolt of oil pump body module
Mounting bolt of front brake cylinder module
Fixing bolt of rear brake rocker arm
Fixing nut of rear wheel
Fixing bolt of welded module of steering handle
Lock nut of front wheel spindle
Front wheel spindle
Fixing nut of rear wheel
Top nut of rear shock absorber
Bottom nut of rear shock absorber
Fixing bolt of rear shelf support
Fixing bolt of fuel tank
Fixing bolt of helmet bucket
Fixing bolt of muffler
Fixing bolt of muffler joint
5-9
22-29
5-9
100-113
40-60
55-62
55-62
100-113
37-44
22-29
5-9
5-9
5-9
22-29
5-9
