107
1. Rear rim 2. Tire 130/70-12 3. Tire valve 4. Brake shoe module 5. Brake shoe tension spring 6. Rear brake
camshaft 7. Rear brake rocker arm module 8. Rear indicator 9. Return spring of rear brake 10. Rear rocker arm bolt
11. Nut 12. Scraper seal 13. Tire valve cap
V. Brake
Maintenance instruction ------------------------ 5.1
Fault diagnosis ----------------------------------- 5.2
Front liquid brake--------------------------------5.3
Rear brake drum ---------------------------------5.4
5.1 Maintenance instruction
Matters needing attention in operation
*Attention
* Inspect the brake before riding the motorcycle.*
5.1.1 Specification
Item Standard value (mm) Allowable limit(mm)
thickness of front brake disc
4.0 3.0
Thickness of front friction
lining
6.0 5.0
Diameter of front brake disc
190 -
Bore of rear brake drum
110 111
thickness of rear brake pad
6.0 5.0
5.1.2 Torque value
Fixing bolt of oil pump components 5-9 N·m
•The braking components can not be spoiled by oil stain in installation or disassembly.
•Rinse with stipulated cleaning agent in order to avoid reduction of braking quality.
