189
XV. Decelerator
Preparation data --------------15.1
Fault diagnosis----------------15.2
Gear case ----------------------15.3
Installation---------------------15.4
15.1 Preparation data
Function: convey the torque and determine the torque and rev of the final output.
15.2 Fault diagnosis
The motor can not move when the engine is started.
The drive gear is broken.
The drive gear is burnt out.
The gear oil is leaked.
The gear oil is too much.
The oil seal is damaged.
15.3 Gear Case
15.3.1 Disassembly
Dismount oil drain nut, drain out oil from the gearbox.
Loosen the bolt and take down the gear case cover.
Gear case cover
Bolt
