Generic Race 50 - Fuel Tank

134
output hanging rack 7 seat mat assembly 8 fuel tank assembly 9 components of seat mat lock 10 screw
M6×20 11 prop for rear luggage rack 12 screw M6×12 13 tight wire of seat mat 14 rivet3.2×7
Fuel tank
A
Fuel capacity ：
5±0.2L
B
Torsion for screw 2：
5-9 N·m
C
Length of the vacuum tube
of the fuel tank：360mm
D
caution：must turn the fuel
switch to the “OFF”
p
osition
