Fuel tank/seat mat
1 welded components for vehicle frame 2 screw axle for engine 3 bolts M12×1.25 4 screw bolts for
hanging rack M10×41×1.25 5 bolts M10×1.25 6 welded components for welded components of power
A
Caution：must turn the fuel
switch to the “OFF”position
when dismantling the fuel
tank
B
Torsion for bolts 4：
37-44 N·m
D Torsion for screw 10：5-9 N·m
To Next Page
