50
Inspection/adjustmentof accelerator's pull
wire
Check the smoothness of accelerator pull wire.
Examination of the free replacement of accelerator stayguy
Free displacement：5-10mm
The main adjusting position is on the carburator side.
Loosen the fixing nut and adjust by turning adjusting nut.
Air cleaner
Replacement of the filtrator
Remove body fender.
Remove fixing bolt (3) of air cleaner cover.
Remove pipe clip (4).
Remove the air filter.
Dismantle the clamping screw of the cover of air filter.
Take down the upper-cover of the filter.
Dismantle the filter element from the filter.
Check to see if the filter element is polluted or damaged.
If it is polluted or damaged, please replace with new one.
Dismantle the clamp component.
Remove the filter.
Check whether the filtrator is polluted or damaged.
If it is polluted or damaged, please replace with new one.
Changing time
If the motorcycle is frequently driven on bad road or in rain,
it should be replaced early.
Mounting bolt M6x20
