119
left rear view mirror components 11 Right rear rearview mirror components 12 Left combination switch
13 left handle 14 Fixed handle screw M5 15 Nut M5 16-17 Right combination switch 17 Flat screw
M5 × 20
VII. Front wheel/ front suspension
Preparation data -------------------------7.1
Fault diagnosis --------------------------7.2
Front wheel ------------------------------7.3
Direction handle-------------------------7.4
Front fork --------------------------------7.5
7.1 Preparation data
Matters needing attention in operation
Before the demolition of the front wheels, the bottom of the body should be supported by jack, and the
front-wheel-floating ground should not be attention to the ground can not be invertible.
During the operating, the brake shoes block, friction-chip components, brake disc can not be attached to oil.
Reference for the entire motorcycle
Measuring position Item
standard value
(mm)
Allowable
limit(mm)
front wheel spindle bending 0.2
vertical direction 2.0
front wheel run-out of rim
transverse direction Within 1.0 2.0
Torque value Tools
The direction knob seal component fix bolt 40-60 N·m Bearing puller
Front axle lock nut 100-113 N·m Lock-in nut wrench
Front axle 100-113 N·m
7.2 Fault diagnosis
7.2.1 It’s hard to rotate the direction handle
Malfunction of the direction handle bearing.
