136
1 components of seat mat 2 components of rotating leaf 3 0 shape ring 84.4×3.1 4 protruding screw
M6×14 5 helmet bucket 6 gasket8 7 screw M6×12 8 rear luggage rack 9 screw nail M8×45 10
plastic gasket 11 bottom lid of helmet bucket
IX. Fuel tank/seat mat
Preparation-------------------------------9.1
Troubleshooting-------------------------9.2
Fuel tank/seat mat-----------------------9.3
9.1 Preparation
Matters needing attention in operation
The place for dismantling should be far away from fire.
must turn the fuel switch to the “OFF” position when dismantling the fuel tank.
Torsion for screwing bolts must meet the determined value.
Check whether all parts are properly mounted and operating after mounting..
Preparation reference
Item Standard Limit for usage
Fuel tank capacity
5±0.2L /
Torsion for screwing down
Screw bolts for rear luggage rack prop 5 - 9 N·m
Screw bolts for fuel tank 5 - 9 N·m
Screw bolts for helmet bucket 5 - 9 N·m
9.2 Troubleshooting
Decrease of fuel quantity
