Generic Race 50 - Page 136

135
1 tank components 2 screw M6×16 3 components of fuel tank switch 4 fuel tube 180mm 5 heat
insulation spring 6 hoopФ8 7 vacuum tube 360mm 8 hoopФ7 9 fuel tube 2250mm 10 filter
components 11 fuel position sensor 12 screw M5×16 13 gasket of fuel position sensor 14 seal
rubber 15 gasket 5 16 filter core 17 sheath gasket
Seat mat
A
Torsion for screw 4：
5-9 N·m
B
Torsion for screw 7：
5-9 N·m
