116
1 Front wheel rim 2 intermediate bushings components 3 SEAL 22Χ35Χ7 4 bearing 6201-2RS 5 tires
120/70-12 6 valve Z2-01-1 7 nut M12 Χ1.25 8 axle M12Χ1.25Χ224 9 Front wheel left axis cover
10 gear wheel bracket component nuts 11 valve cap
A
Tire specifications: outer
tire120/70-12
B
Wheels specifications:
3.50 × 12
C
Rims facing poor limits:
vertical: 2.0 mm
horizontal: 2.0 mm
D
Front wheel axle degree
limits: 0.2 mm
E
Outer tire of front wheel
certification of: E11 75R
