Generic Race 50 - Page 147

146
Oil pump assembling
Shown in the following Fig.
10.3.2 Installation
Carry out the installation according to the reversed sequence
of dismantle.
10.3.3 Inspection
Inspect worm wheel teeth surface whether there is damage.
Inspect key slot whether there is breakage.
Oil pump cover
Oil pump shanft
Gear
Oil pump body
Element outside diameter
Element spring
Element
