45
Specification
Engine
Gyration speed at idle speed
1750±100rpm/min
Spark plug gap
0.6-0.7mm
Spark plug specification
BR7ES (NGK/TORCH)
Carriage
Free stroke of front brake drawbar 10-20mm
Free stroke of rear brake drawbar 10-20mm
Specification Tire pressure
Outer cover of front
wheel
120/70-12
Front rim 3.50×12
145-170kpa
Outer cover of rear wheel
130/70-12
Tire pressure unit：Kpa
RACE 50
Rear rim 3.50×12
170-195kpa
front wheel-axle
clamping nut
100-113 N·m Torque
force
value
rear wheel fixed nut 100-113 N·m
Certification of related components
Sort Name Certification number
Outer cover of front wheel
E11 75R 000210
Tire
Outer cover of rear wheel
E11 75R 000216
Head lamp
E4 0012026
Tail lamp
E11 000054
Light fitting
Front turn signal lamp
E3 001024
