57
Gear mobile oil
Inspection
*Attention
Fuel check, let down the middle supporter to be
perpendicular to motorcycle on the flat floor.
Dismantle the inspection bolt of gear oil after stopping
engine.（1）.
The oil level is below the lower limit of bolt hole is good.
Please supplement gear oil when the oil level is too low.
Install the inspection bolt of gear oil.
*Attention
Confirm the airtightness of bolt and whether it is out of clutch and damage.
Changing gear oil
Dismantle the inspection bolt of gear oil.
Dismantle the oil drain bolt（1），the gear oil will effuse.
Install the oil drain bolt.
*Attention
Confirm the airtightness of bolt and whether it is out of clutch and damage.
Supplement gear oil.
Check the oil leak of each position after operation.
Install the inspection bolt of gear oil.
Driving chain
Dismantle the left crankcase lid.
