2.4.2 Inspection
Disassemble the CDI group and inspect whether the joint is
loosen or eroded.
Inspection item Testing terminal Standard value （20）
Main switch red—red/white Conducted when main switch at "
OFF "
Trigger Blue/white—white green 100-500Ω
primary ignition coil black/white—black 0.6Ω±10％
Secondary ignition coil black—spark plug cover（spark
plug not included）
0.5-5.5KΩ
