Geodesic Sensor Net Technical Manual
S-MAN-200-GSNR-001 • January 31, 2007
Sensors
41–50 Pin
Sensors
51–60 Pin
Sensors
61–70 Pin
Sensors
71–80 Pin
41 5A 51 6A 61 7A 71 13A
42 5B 52 6B 62 7B 72 13B
43 5C 53 6C 63 7C 73 13C
44 5D 54 6D 64 7D 74 13D
45 5E 55 6E 65 7E 75 13E
46 5F 56 6F 66 7F 76 13F
47 5G 57 6G 67 7G 77 13G
48 5H 58 6H 68 7H 78 13H
49 5J 59 6J 69 7J 79 13J
50 5K 60 6K 70 7K 80 13K
Sensors
81–90 Pin
Sensors
91–100 Pin
Sensors
101–110 Pin
Sensors
111–120 Pin
81 14A 91 15A 101 16A 111 17A
82 14B 92 15B 102 16B 112 17B
83 14C 93 15C 103 16C 113 17C
84 14D 94 15D 104 16D 114 17D
85 14E 95 15E 105 16E 115 17E
86 14F 96 15F 106 16F 116 17F
87 14G 97 15G 107 16G 117 17G
88 14H 98 15H 108 16H 118 17H
89 14J 99 15J 109 16J 119 17J
90 14K 100 15K 110 16K 120 17K
Sensors
121–COM Pin
Sensors
GND–
???? Pin
121 18A GND 19A
122 18B AMP0 19B
Note: The pin-
numbering scheme
jumps from 7 to 13
because rows 8–12
are occupied by the
pin (see Figure C-1).
Also, 32-channel
Nets do not contain
row 19.
123 18C AMP1 19C
124 18D AMP2 19D
125 18E ???? 19E
126 18F GSN0 19F
127 18G GSN1 19G
128 18H GSN2 19H
REF 18J GSN3 19J
COM 18K ???? 19K
Table C-2. Sensor to 32-, 64-, and 128-pin plug
