Geodesic Sensor Net - Page 9

ix
Geodesic Sensor Net Technical Manual
S-MAN-200-GSNR-001 • January 31, 2007
L IST OF F IGURES
chapter 1 GSN Introduction
1-1 The GSN 200 (left) and the HCGSN (right)
21
1-2 Core components
24
1-3 Subject wearing an HCGSN
25
1-4 Functional block diagram of a typical GES
25
1-5 Sensor array and Neurotravel amplifier
26
1-6 GSN, GSNIC, and Net Amps amplifier
26
chapter 2 HCGSN
2-1 128-channel HCGSN, front (left) and side (right) views
29
2-2 HCGSN (128-channel model)
30
2-3 HCGSN (128-channel model)
31
2-4 HydroCel Hydrating Skin Interface Chamber
32
2-5 Electrode
34
2-6 Pedestal and electrode
35
2-7 Sensor connected by wire to pin
35
2-8 Sensor cut-away view
35
2-9 The HCGSN comes in adult (left) and child (right) sizes
36
2-10 Outrider sensor
37
2-11 Elefix gel
37
