1.6.6
IMPORTANT PAGES CHAPTER 6
GEODIMETER SYSTEM 600
General measurement hints (cont)
How to combine labels 26, 27, 28 and 29
1. Positioning of HA and VA
If you wish to aim at a point when you know HA and VA
you should use label 26 and 27.
2. Set out points with bearing and distance
If you know the bearing and the distance to a point you
should use label 27 and 28. With label 29 you can also set
out the height.
Note - Do not use label 26 for positioning the height of
the point. Use instead label 29 and let the instrument
calculate the VA.
3. Set out points with known coordinates
If the station is established (via program 20 or menu 3)
you can use label 67 and 68. With label 69 you can also
set out the height.
Note - If you use label 67, 68 or 69, this will also have
effect on label 27 and 28.
4. Set out points in height with the servo control key
To position the height use the button. If the distance
has not yet been measured, the instrument will be
positioned in height based on the theoretical distance.
If the distance has been measured the instrument will be
positioned in height to the measured point, i.e. the height
will always be correct even if you do not aim exactly at
the correct point.
Fetch Station data (MNU 33)
If you have established a station with program 20 and the
station coordinates is somehow destroyed (e.g. with an
overriding U.D.S. containing station, IH, Refobj.), you
can retrieve the original station coordinates with menu
3.3. Note ! This does not work if label 21 has been
changed.
