GEODIMETER SYSTEM 600
Measurement keys
Start of measurement cycle (STD, FSTD, D-bar). Internal
storage of angle values in C2 and C1.
A/M-key at the front (on instruments with no front panel)
when measuring in two faces (C1 and C2).
Registration key
For registration of measurement values. (In FSTD working
with UDS this key both measures and registrates with a
single press.
Example:
Alphanumeric input using the ASCII table
A/M
REG
REG
α
It is also possible to enter alpha characters in instruments
with the numeric control unit. This is done by pressing the
REG-key/ASCII-key. If alpha characters are to be used in the
middle of an numeric point number or point code title, exit
from and re-entry into the alpha mode is achieved by pres-
sing the REG/ASCII key. Follow the example below.
The instrument also gives you the oppurtunity to select
special characters for different languages. This can be done
via Menu 6.6. A complete list of values for different charact-
ers for different languages is shown on page 1.6.2.
The point number to be keyed in is 12 MH 66 which is the field
notation for Point Number 12, which happens to be a manhole
with a 66 cm diameter cover.
Press F5 and ENT. PNO is seen on the display. Key in 12. Press
the REG-key/Alpha-key. ASCII is seen on the display. Key in 77 72
= MH. Press once again the REG/Alpha key. Then key in 66.
Finalize the keying in by pressing the ENT key. This ASCII possibi-
lity can of course be used with other functions – e.g. Operator,
Project, etc.,etc.– in fact all functions except the labels which are
directly connected with measured and calculated survey values.
Alpha character keying in (numeric control unit)
