1.1.23
INTRODUCTION CHAPTER 1
GEODIMETER SYSTEM 600
For activation / deactivation of the Alpha Mode. When the
alpha mode is activated, it is indicated by an (a) symbol in
the right-hand corner of the display.
It is also possible to enter alpha characters in instruments
with a numeric control unit, see page 1.1.22.
Alpha mode key (alphanumeric control unit)
How to use the alphanumeric keys (alphanumeric control unit)
The numerical keys can be used both for ordinary numerals
and letters. To use the letters as indicated on each key, first
press key the keyboard is now locked for letters, and
this is indicated by an (α) symbol in the upper right hand
corner of the display. To enter a particular numerical
character in combination with an alpha character, press the
key . A (^) symbol in the upper right-hand corner of
the display window indicates that the shift key is activated.
For small letters, press shift directly followed by
"Lower Case" .
The figure (1) in the upper right-hand corner of the display
window will appear immediately indicating lower case mode.
To return to numerical keys, press key .
The instrument also gives you the opportunity to select
special characters (not shown on the keyboard). The special
characters differ between languages. Language is changed via
Menu 66. These special characters are displayed in the
bottom row in groups of five.To step between the different
characters press keys and .
The characters are entered by first pressing shift and then the
corresponding key below the character.
Lower case key (alphanumeric control unit)
Lower case is used together with the Shift key to be
able to use the alphanumeric keyboard with lower case
letters. This is indicated by the figure "1" in the right hand
corner of the display.
α
Lc
α
α
Lc
CON
Note!
☛
