1.3.8
STATION ESTABLISHMENT CHAPTER 3
GEODIMETER SYSTEM 600
Station data (Instr. Height, Signal Height, Stn. Coord.)
To work with direct and immediate calculation of point
coordinates and elevations, the operator can easily and
quickly key in the instrument station coordinates via the
main menu, option 3, Coord, or option 1, Stn. Coord. or
with F37, F38 and F 39. Instrument and signal height can be
keyed in via functions F3 and F6 respectively.
Let us begin this example by informing the instrument of the
station data i.e. instrument height, signal height, instrument
station coordinates and in that order.
STD P0 10:16
HA: 234.5678
VA: 92.5545
STD P0 10:16
IH = 0.000_
STD P0 10:16
HA: 234.5678
VA: 92.5545
To inform instrument of the instru-
ment height, we will select function
3.....
The previous value is shown. Accept or
key in new I.H.
You are now returned to the STD P0.
Repeat the above instruc-tions with
function 6 (F6) to key in the signal
height (SH).
After keying in IH (F3) and SH (F6),
choose the menu function to access the
"3 Coord" option.
Instrument
Height
Signal
Height
See next page
MNU
F
3
ENT
F
3
ENT
F
6
To Next Page
