1.3.7
STATION ESTABLISHMENT CHAPTER 3
GEODIMETER SYSTEM 600
STD P0 10:16
HA: 234.5678
VA: 92.5545
Key in the distance correction offset or
accept zero value (Default value = 0).
See also prism constant, chapter 1.6.
Key in a new HA bearing, e.g.
234.5678, zero, or accept displayed
value .
Aim instrument to R.O. (Reference
Object) and press A/M or ENT.
Note!
If you use F21 to preset the HAref
angle, the instrument must be pointing
at the R.O. before pressing the ENT
key.
The instrument automatically assumes
the standard (STD) mode and it is now
orientated to your own local coord.
system.
(cont) Pre-Setting of Temp, Press., Hum., Offset and HAref.
Note!
ā
P0 10:16
HA: 123.4567
HAref= _
P0 10:16
HA: 123.4567
HAref= 234.5678
From previous page
ENT
At this stage you could start to choose which measurement
mode you are going to use ā i.e. D-bar, Tracking and Stan-
dard (automatically selected). But let's continue by setting the
station data.
P0 10:16
Offset = 0.000_
ENT
ENT
To Next Page
