Administrator Mode
137
4 4
[Optional Network Type]
Note the Wireless Settings are only available in GV-BX1200 Series / 1500
Series / 2400 Series / 2500 Series / 2700 Series / 3400 Series / 4700
Series / 5300 Series / 5700 Series, GV-CAW120 / 220, GV-FER5700 and
GV-MFD1501 Series / 2401 Series / 2501 Series / 3401 Series / 5301
Series. According to the network environment, select Wired Ethernet or
Wireless. Before enabling the Wireless option, follow the steps in 2.1.3
Configuring the Wireless Connection to configure the wireless settings first.
[LAN Configuration]
Dynamic IP address: The network environment has a DHCP server
which will automatically assign a dynamic IP address to the camera.
Click the Test DHCP button to see the currently assigned IP address
or look up the dynamic IP address using GV-IP Device Utility.
Static IP address: Assign a static IP or fixed IP to the camera and fill
out the required settings. The default values are as below.
PPPoE: The network environment is xDSL connection. Type the
Username and Password provided by ISP to establish the connection.
If you use the xDSL connection with dynamic IP addresses, first use
the DDNS function to obtain a domain name linking to the camera’s
changing IP address.
Wired Ethernet Wireless
IP address 192.168.0.10 192.168.100.10
Subnet Mask 255.255.255.0 255.255.255.0
Router/Gateway 192.168.0.1 192.168.0.1
Primary DNS server 192.168.0.1 192.168.0.1
Secondary DNS server 192.168.0.2 192.168.0.2
To Next Page
