Operating Your Computer 2-23
Using the LAN
NOTE: To take advantage of the LAN feature, the device driver supplied with your
computer must be installed.
The internal 10/100/1000Base-T LAN (Local Area Network) module
allows you to connect your computer to a network. It supports data
transfer rate up to 1000 Mbps.
To connect the network cable to the LAN module, connect one end of the
LAN cable to the RJ-45 connector on the computer and the other end to
the network hub.
IMPORTANT: If there is no signal detected on the LAN cable when system is using battery
power, connect to AC power or disable the “NIC Auto Power Control” item on the Advanced menu
in BIOS Setup (see chapter 5 for details).
