Fault indications and troubleshooting
6
Service instructions
5015108-00 Edition 0403
Fault code Fault Comment
F06 Fault door, dirty side The door does not unlock (-S01) within 10 seconds.
Possible action:
a. Check whether the microswitch (-S01) for the “door open” limit position has
been activated within 10 seconds on door unlocking.
b. Check that the motor (-M10) and the switch (-S51) for door unlocking are working.
F07 Fault door, dirty side Door does not lock (-S03) within 20 seconds or opens while a program is
running. (Machine with automatic door only.)
Possible action:
a. Check that nothing is trapped in the door.
b. Check whether the microswitch (-S03) for closed door limit position has been
activated for 20 seconds.
c. Check that the motor (-M09) and the switch (-S53) for door locking are working.
d. Check the chain.
F08 Fault door, dirty side The door does not open (-S04) within 20 seconds. (Machine with automatic door only.)
Possible action:
a. Check that nothing is trapped in the door.
b. Check whether the microswitch (-S04) for closed door limit position has been
activated for 20 seconds.
c. Check that the motor (-M09) and the switch (-S54) for door opening are working.
d. Check the chain.
F09 Faulty door, clean side Door does not lock (-S05) within 10 seconds or opens while a program is running.
Possible action:
a. Check whether the microswitch (-S05) for the “door locked” limit position has
been activated within 10 seconds on door locking.
b. Check that the motor (-M12) and the switch (-S55) for door locking are working.
F10 Faulty door, clean side The door does not unlock (-S06) within 10 seconds.
Possible action:
a. Check whether the microswitch (-S06) for the “door open” limit position has
been activated within 10 seconds on door unlocking.
b. Check that the motor (-M12) and the switch (-S56) for door unlocking are working.
F11 Faulty door, clean side Door does not lock (-S07) within 20 seconds or opens while a program is
running. (Machine with automatic door only.)
Possible action:
a. Check that nothing is trapped in the door.
b. Check whether the microswitch (-S07) for closed door limit position has been
activated for 20 seconds.
c. Check that the motor (-M11) and the switch (-S57) for door locking are working.
d. Check the chain.
