As for the individual inputs, the G3 module offers you a fully
parametric 3-band equalizer as well as a compressor for the
master and headphone outputs.
MASTER COMPRESSOR &
HEADPHONES COMPRESSOR
With the compressor, a smoother audio output can be
achieved. Unwanted peaks can be lowered and quiet
sounds can be raised.
MASTER EQUALIZER (EQ) &
HEADPHONES EQUALIZER (EQ)
The EQ on the G3 affects the volume of the three frequency
ranges (LOW / MID / HIGH).
Select the desired menu item with the dial [5] or the
navigation keys [8].
Open the respective menu with [F1] or with [8] [ENTER].
Press [F3] to exit the level or any menu key to exit the
entire menu.
The operation of the individual parameters is identical to that of the Channel EQ and Channel Compressor
settings. You will find more detailed information in the chapter: Equalizer & Compressor
