GF EA Series User Manual

About this document Instruction manual
42
Other symbols
Symbol Meaning
1.

Call for action in a certain order: Here, you have to do something.
Call for action without fixed order.
Remarks: Contain especially important information for better understanding.
2.2 Further applicable documents
• Georg Fischer industrial planning fundamentals
• Instruction manual accessories
• Instruction manual of the respective manual valve
These documents can be obtained via the agency of GF Piping Systems or under www.gfps.com
.
2.3 Product variants and types d e sc ri b e d
• Type EA25 24V AC/ DC and 100 – 230V AC
• Type EA45 24V AC/ DC and 100 – 230V AC
• Type EA120 24V AC/ DC and 100 – 230V AC
• Type EA250 24V AC/ DC and 100 – 230V AC
The manual covers standard and cUL-marked actuators. Table below states the two
types and valid order codes:
Standard Type Voltage Code Electrical connection
EA25
100
-230V AC
198153182
DIN
-plug / cable gland
EA25
24V AC/DC
198153183
DIN
-plug / cable Gland
EA45
100
-230V AC
198153184
DIN
-plug / cable gland
EA45
24V AC/DC
198153185
DIN
-plug / cable gland
EA120
100
-230V AC
198153186
DIN
-plug / cable gland
EA120
24V AC/DC
198153187
DIN
-plug / cable gland
EA250
100
-230V AC
198153188
DIN
-plug / cable gland
EA250
24V AC/DC
198153189
DIN
-plug / cable gland
UL marked types
Voltage
Code
Electrical connection
EA25
cUL marked*
100
-230V AC
198153202
Cable gland only
EA25
cUL marked*
24V AC/DC
198153203
Cable gland only
EA45
cUL marked*
100
-230V AC
198153204
Cable gland only
EA45
cUL marked*
24V AC/DC
198153205
Cable gland only
