Page #54 background image
Technical specifications Instruction manual
54
6 Technical specifications
EA 25 EA 45 EA 120 EA 250
Power input max.
45 VA
65 VA
60 VA
70 VA
Current (calculated)
0.35A at 100V
0.15A at 230V
0.55A at 100V
0.24A at 230V
0.5A at 100V
0.22A at 230V
0.55A at 100V
0.26A at 230V
1.7A at 24V 2.5A at 24V 2.3A at 24V 2.7A at 24V
Nominal torque Mdn
(peak)
10 (25) Nm 20 (45) Nm 60 (120) Nm 100 (250) Nm
Duty cycle
100 % 50 % 50 % 35 %
Cycle time s/90°
at Mdn
5 s 6 s 15 s 20 s
Flange fitting
F05 F05 F07 F07
Tested cycles
(at 20 °C and Mdn)
250 000 100 000 100 000 75 000
Weight
2.1 kg 2.2 kg 3.6 kg 5.0 kg
Actuating angle
Max. 355°, set to 90°
Power Supply
AC: 100 230 V, 50/60 Hz
AC/DC: 24 V, 50/60 Hz
Supply voltage
tolerance
± 15 %
Protection class
IP 65 (IP67)1) per EN 60529
Designed for wet & dry locations (NEC), designed for indoor use
(UV light may cause discoloration)
Pollution degree
Operation: Pollution Level 3
Commissioning (open cover):
Only in controlled environments of pollution level 2
Overload protection
Current/time dependent, resetting
Overvoltage category
II
Fuse
Internal: SMD fuse 2 A, not replaceable.
Req. external breakers on all live wires:
Rated Current: max. 16A
Trip Curve: C,
Standards Compliance: cUL489, CSA C22.2 No. 5.1, IEC 60947-2
Ambient temp.
-10 °C to +50 °C (14°F to 122°F)
Max. installation
altitude
2000m above sea level (AMSL)
