Function: Safety edge function in the pre-limit area
Menu item "2.1":
Function Reaction to activation of safety edge
„.1“ Active Door stops
„.2“ Inactive
No reaction
Door moves to CLOSE final limit position
„.3“ Ground adjustment (DES)
Door stops; correction of the CLOSE final limit position at
the next closing
„.4“ Reversing in overrun area
(DES)
Reversing upwards from the overrun area upon activation
of the safety edge system
Note: Ground adjustment!
Automatic compensation of rope elongations or changes in ground conditions
of approx. 2-5 cm
With DES limit switch only
Do not use with overrun correction
Do not use with pneumatic switch
Note: Reversing upwards in the overrun area!
To maintain the operating forces in the pre-limit area
At high speeds
With DES limit switch only
Function for FI-drive units not necessary
