WindMaster and WindMaster Pro 1561-PS-0001. Issue 11 February 2017
________________________________________________________________________________________________________________________
56
Nx – Set unit ID
Sets the unit ID displayed at the start of all GILL communications strings
Set Q (default), …from A to Z Command N<Q>
Ox – Set ASCII output format
1 Comma Separated Variable (CSV) format
2 Fixed field
Example string for CSV data changing to an error status code condition.
Q,335.3,001.261,-001.282,M,+345.41,+023.05,00,+2.4181,+2.4181,+2.4162,+2.4175,- 50.00C, 78
Q,,,,M,,,07,+2.4181,+2.4187,+2.4162,+2.4175,- 50.00C, 72
Example string for Fixed Field data changing to an error status code condition.
Q,251.7,000.860,-000.401,M,+346.43,+024.80,00,+2.4181,+2.4187,+2.4169,+2.4175,- 50.00C, 7F
Q,999.9,999.999,+999.999,M,+999.99,+999.99,07,+2.4181,+2.4187,+2.4169,+2.4181,- 50.00C, 77
Px – Set output rate
Note: the P9 setting is an option on the WindMaster unit, which must be specified at the time of ordering.
1 Rate is 1 Hz (20Hz Sampling)
2 Rate is 2 Hz (20Hz Sampling)
3 Rate is 4 Hz (20Hz Sampling)
4 Rate is 5 Hz (20Hz Sampling)
5 Rate is 8 Hz (32Hz Sampling)
6 Rate is 10 Hz (20Hz Sampling)
7 Rate is 16 Hz (32Hz Sampling)
8 Rate is 20 Hz (20Hz Sampling)
9 Rate is 32 Hz (32Hz Sampling)
20 Rate is ¼ Hz
21 Rate is ½ Hz
Sx – Analogue output range
This sets the velocity scaling for the analogue output. (see also Para 9.5).
1 Full range is 5m/s
2 Full range is 10m/s
3 Full range is 20m/s
4 Full range is 30m/s
5 Full range is 40m/s
6 Full range is 50m/s
7 Full range is 60m/s
8 Full range is 120m/s
