GMI PS200 series - Page 34

2-12
USER HANDBOOK
The example in Fig. 2-15 illustrates the maximum
(MAX) gas values stored in a 4-gas instrument.
Fig. 2-15 Maximum Gas Values
2) Press the Right Hand (RH) button again to
view the minimum gas values stored in the instrument.
Note: This screen is only displayed when an Oxygen
sensor is fitted in the instrument.
The example in Fig. 2-16 illustrates the minimum (MIN)
gas values stored in a 4-gas instrument.
Fig. 2-16 Minimum Gas Values
