2-15
OPERATION
2.6.1 Pump Operation:
Press and hold the Right Hand (RH) button to start or
stop the pump.
When the pump is running, a pump symbol , illustrated
in Fig. 2.18, rotates in the display.
Note 1: It is only possible to switch the pump ON / OFF
when instrument alarms are inactive.
Note 2: Pump cannot be switched OFF if instrument is
configured with setting ‘PUMP ALWAYS ON’.
Fig. 2-18 Pump Symbol Displayed
2.7 SELF TEST
The PS200 series instrument has the ability to perform a self
test. The test can be performed any time during normal
operation of the instrument.
In this mode, the instrument tests the buzzer, LED’s,
vibration function and displays both the flammable gas type
used for calibration and the current username.
To perform a self test, press and hold the Left Hand (LH)
button
.
To Next Page
