860-7200-18 DTU DTB Service & Maintenance Manual
LOCATION: Base Frame GREASE
ITEM PART INTERVAL FITTING TYPE QTY
Drive Wheel Bearings Every 1,000 hours Straight
NLGI 2 grease such as
Castrol MP
Thin layer
Front Caster Every 1,000 hours None
NLGI 2 grease such as
Castrol MP
Thin layer
NOTES
Remove oor plates to access drive motors, wheel bearings and the two grease nipples on the casters. Four wheel
bases also have two bearings to grease on pivot - front center of base.
Left and right drive wheel bearings (under oor plates)
Front caster on base frame (under oor plates)
9.5 9.6
9.5
9.6
