860-7200-18 DTU DTB Service & Maintenance Manual
LOCATION: Middle Conveyor Support GREASE
ITEM PART INTERVAL FITTING TYPE QTY
Slewing Bearing Every 2,000 hours Straight
NLGI 1 grease such as
Castrol HD Lithium 1
Thin layer
Rotate Brake Mounting Bolts Every 2,000 hours None
White lithium grease such
as Unival #8631-723
Thin layer
NOTES
Slewing Bearing has 2 grease nipples on inner ring�
LOCATION: Operator Platform (Left Mast) GREASE
ITEM PART INTERVAL FITTING TYPE QTY
Cylinder Lift Chain Every 1,000 hours None
Caster oil such as Molub-
Alloy Chain Oil 22 Spray
Spray entire
chain
NOTES
Remove Lexan cover and spray entire chain with platform fully raised�
Slewing bearing (under middle conveyor or center of machine)
Slewing bearing (under middle conveyor or center of machine)
Rotate brake mounting bolts (under rear of middle conveyor)
8.1
8.1
8.4
8.1
7.4
8.4
