Technical Specifications
100 333587B
Technical Specifications
E-Flo iQ Dispense Systems
US Metric
Maximum fluid operating temperature 158°F 70°C
Maximum working pressure 4000 psi 28 MPa, 276 bar
Maximum driver cycle rate 25 cycles per minute
Air inlet size (supply system) 3/4 npt(f)
Ambient operating temperature range (supply
system)
32-120°F 0-49°C
Displacement pump effective area See pump manual.
Wetted parts See component manual. See Related Manuals on page 3.
Platen wetted materials
25R096, 5 gal. (20 L)
Electroless nickel plated ductile iron, Neoprene, PTFE coated
aluminum, 6061 aluminum, Buna, Viton, Zinc plated steel, 316
stainless steel, 17-4 stainless steel
25R098, 5 gal. (20 L)
Electroless nickel plated ductile iron, Neoprene, PTFE coated
aluminum, 6061 aluminum, Buna, Viton, Zinc plated steel, 316
stainless steel, 17-4 stainless steel
25R097, 5 gal. (20 L)
Electroless nickel plated ductile iron, EPDM, PTFE coated
aluminum, 6061 aluminum, Buna, Viton, Zinc plated steel, 316
stainless steel, 17-4 stainless steel
25R099, 5 gal. (20 L)
Electroless nickel plated ductile iron, EPDM, PTFE coated
aluminum, 6061 aluminum, Buna, Viton, Zinc plated steel, 316
stainless steel, 17-4 stainless steel
255319, 55 gal. (200 L)
319 cast aluminum, EPDM, zinc plated carbon steel, 316 stainless
steel, 17-4 stainless steel
255320, 55 gal. (200 L)
319 cast aluminum, neoprene, zinc plated carbon steel, 316
stainless steel, 17-4 stainless steel
Sound pressure, measured per EN ISO 11202:2010
Normal operation (dispensing) < 70 dBA
Drum Change 77 dBA
Electrical requirements
Ambient system electrical ratings 200-240 VAC, 1 phase, 50/60 Hz, 20 A
Heated system electrical ratings
200-240 VAC, 1 phase, 50/60 Hz, 64 A
200-240/400 VAC, 3 phase, 50/60 Hz, 38 A
Fluid outlet size
Check-Mate 200 1 in. NPT female
Maximum air input pressure (supply system)
D60 - 3 in. dual post, 5 gal. (20 L) 150 psi 1.0 MPa, 10 bar
D200 - 3 in. dual post, 55 gal. (200 L) 150 psi 1.0 MPa, 10 bar
D200s - 6.5 in. dual post, 55 gal. (200 L) 125 psi 0.9 MPa, 9 bar
