Dispense System Components
NOTE: The Heated option for the E-Flo iQ system is for warm melt applications with a maximum temperature of 70° C
(158° F).
iQ Ram Supply Units
Check the identification plate (ID) on the back of the ram post near the Power Junction Box (AJ) for the seven-digit part
number of the iQ ram supply unit. Use the following matrix to define the construction of the unit, based on the seven digits.
For example, Part No. EZC2422 represents an electric supply unit (EZ), a carbon steel Check-Mate 200 Severe Duty dis-
placement pump (C2), a 3 in. ram (4), a 5-gallon platen with a neoprene seal (2), and an ADM (2).
The digits in the following matrix do not correspond to the reference numbers in the Parts drawings and lists.
KEY:
EZ C2 4
22
First
and
Second
Digit
Third and Fourth Digit Fifth Digit
Sixth Digit
Seventh
Digit
Check-Mate Pump Options Ram Options
Platen and Seal Options
Interface
Options
Size
Pump
Material
Heated/
Ambient
Name Size
Drum
Size Style
Platen
Size
Platen
Material
Seal
Material Wiper
Heated/
Ambient Interface
EZ
(Electric
Supply
System)
C1 200cc CS Ambient
1 D60 3 in.
20 L
(5 Gal) Ambient 1
20 L
(5 Gal) CST/AL Neoprene
Single
Ring Ambient 2ADM
C2 200cc CS Heated
<70° C 2 D200 3 in.
200 L
(55 Gal) Ambient 2
20 L
(5 Gal) CST/AL Neoprene
Single
Ring
Heated
<70° C 4No ADM
C3 200cc CM Ambient
3 D200s 6 in.
200 L
(55 Gal) Ambient 3
20 L
(5 Gal) CST/AL EPDM
Single
Ring Ambient
C4 200cc CM Heated
<70° C 4 D60 3 in.
20 L
(5 Gal)
Heated
<70° C 4
20 L
(5 Gal) CST/AL EPDM
Single
Ring
Heated
<70° C
5 D200 3 in.
200 L
(55 Gal)
Heated
<70° C 5
200 L
(55
Gal) AL Neoprene
Double
Ring Ambient
6 D200s 6 in.
200 L
(55 Gal)
Heated
<70° C 6
200 L
(55
Gal) AL Neoprene
Double
Ring
Heated
<70° C
7
200 L
(55
Gal) AL EPDM
Double
Ring Ambient
8
200 L
(55
Gal) AL EPDM
Double
Ring
Heated
<70° C
CS = Carbon Steel Severe Duty
CM = Carbon Steel MaxLife
CST/AL = Carbon Steel/Aluminum
AL = Aluminum
